Turret PID control for FTC

Our shooter turret needs to track a goal while the drivetrain moves underneath it. That means the controller can't just chase a setpoint — it has to reject the disturbance of the whole robot rotating. This is the controller we ran at regionals, plus the two bugs that cost us a match each.

The core is an ordinary PID with a velocity feedforward term from the drivetrain's measured yaw rate. The interesting part is the error calculation: a turret is circular, so the error between target and current angle must wrap to the shortest path.

public class TurretController {
    private final PIDCoefficients k;
    private double integral = 0, lastError = 0;

    public double update(double targetRad, double currentRad,
                         double robotYawRateRadPerSec, double dt) {
        // Wrap error to (-π, π] so the turret never takes the long way around.
        double error = AngleUnit.normalizeRadians(targetRad - currentRad);

        integral += error * dt;
        double derivative = (error - lastError) / dt;
        lastError = error;

        // Feedforward cancels the robot's own rotation before PID sees it.
        double ff = -robotYawRateRadPerSec * k.kV;

        return k.p * error + k.i * integral + k.d * derivative + ff;
    }
}

Bug one: we integrated error before wrapping, so a target crossing the ±180° seam dumped a huge spike into the integral term and the turret wound up against its hard stop. Bug two: dt came from System.nanoTime() deltas but we reset the timer in a different method than we read it, so the first loop after enable saw a dt of several seconds and the derivative term kicked like a mule.

Tuning order that worked: kV first with PID zeroed (drive in circles, watch the turret hold), then p until it oscillates, then d to kill the oscillation, and i last and reluctantly — with the feedforward doing its job, we ended up leaving i at zero.
